1500w Raycus Laser Metal Cutting Machine RF-1325-1500 for Steel Copper Aluminum



Feathers of  Laser Metal Cutting machine RF-1325-1500:

A. High precision, fast speed, narrow cutting seam

minimum heat-affected zone, smooth cutting surface without burrs;

    B. High technology laser head

    The laser cutting head does not touch the surface of the material and will not scratch the workpiece;

    C. High precision cutting performance

    The slit is the narrowest, the heat-affected zone is the smallest, the local deformation of the workpiece is small, and there is no mechanical deformation;

    D. Advanced working technology

    Good processing flexibility, can process any graphics, and can also cut pipes and other profiles

    E. Wide rang of cutting materials

    It can cut steel plate, stainless steel, aluminum alloy plate, cemented carbide and other materials with any hardness without deformation

    F. Beam quality

    smaller focused spot, finer cutting lines, higher work efficiency and better processing quality;

    G. Fast Cutting speed

    2 times of the same power CO2 laser cutting machine;

    H. Stability

    Using high-performance fiber laser, stable performance.

    I. High electro-optical conversion efficiency

    energy saving and environmental protection;

    K. Cost of use

    The power consumption of the whole machine is lower than that of CO2, which saves production costs

    L. Maintenance cost is low

    No laser working gas; optical fiber transmission, no need for reflective lenses; it can save a lot of maintenance costs;

    M. Product operation and maintenance is convenient

    optical fiber transmission, no need to adjust the optical path;

    N. Flexible light guide effect good

    small size, compact structure, easy to flexible processing requirements

    AUTO focus fuction------this fiber laser cutting machine is adopted laser head Raycus BM109 model that can adjust the fucos point automatically as per sheet height (THIS FUNCTION FOR YOUR OPTION)


    Cutting materials of 1500W LASER METAL CUTTING MACHINE:
    1. Stainless steel:(1-8mm)
    The fiber laser cutting machine has a very good cutting effect on stainless steel thin plates. stainless steel plates and pipes of various thicknesses can achieve near-perfect cutting results.
    2. Alloy steel:(1-16)
    Most alloy steels can be cut by laser and the cutting edge quality is good.
    3. Carbon steel:(1-16mm)
    Carbon steel is also the industry with the most applications of fiber laser cutting. In the industrial field, carbon steel materials of almost all thicknesses can be cut with fiber laser cutting machines.
    4. Aluminum and alloys:(1-5mm)
    Aluminum alloy material is also a big application. Aluminum alloy material is mainly used in the building door and window hardware industry. It can also be processed by laser cutting machine.
    5. Other metal materials:
    Copper, brass, red copper, galvanized sheet, manganese steel and other materials are suitable for processing with fiber laser cutting machine.
    6. Titanium and its alloys. When oxygen is used as the auxiliary gas, the chemical reaction is violent and the cutting speed is fast, but it is easy to form an oxide layer at the cutting edge and may also cause overburning. Therefore, using air as the auxiliary gas can ensure the cutting quality.
    Laser cutting of titanium alloy commonly used in the aircraft industry is very good. Although there will be a little sticky residue at the bottom of the cut, it is easy to remove. The titanium sheet is cut with nitrogen and air as the processing gas.
    7. Copper and its alloys. Basically, CO2 laser beams cannot be used for cutting. Higher laser power should be used for cutting brass (copper alloys). Air or oxygen is used as the auxiliary gas, which can cut thinner plates.
    Both pure copper and brass have high reflectivity and very good thermal conductivity. Brass with thickness below 1mm can be cut with nitrogen;
    Copper with a thickness of less than 2mm can be cut, and the processing gas must be oxygen. Pure copper and brass can be cut only when a "reflection absorption" device is installed on the system, otherwise the reflection will destroy the optical components.


    The components of laser metal cutting machine RF-1325-1500:
    A. Fiber laser source:
    It is the core component of the fiber laser cutting machine, and also the "power source" for the laser cutting machine to realize the cutting operation. We have IPG/Raycus/JPT/MAX etc source for your option

    B. Laser cutting head
    The laser cutting machine is a laser output device, different power we advise differnt laser head models
    1)BT240S-0003 is suitable for 1000w 1500w Hand Focus.
    2)BT240S-0005 is suitable for 2000w 3000w Hand Focus.
    3)BM109 is suitable for 1000w 1500w Auto Focus.
    4)BM111 is suitable for 2000w 3000w Auto Focus.
    5)BM114 is suitable for 4000w 6000w Auto Focus.
    For higher Power laser cutting for steel machines,we will recommend Precitec fiber laser cutting head,it will be more stable and better maintaince.

    C. servo motor
    Servo motor refers to the engine that controls the operation of mechanical components in the servo system
    We use Japan Yaskawa servo motor and drivers and Delta Taiwan servo motor and drivers

    D. Chiller
    The chiller is the cooling device of the laser cutting machine, which can cool the laser, spindle and other devices quickly and accurately.
    We use top quality S&A water chiller

    E. Gas supply system( for your option)
    The gas supply system of fiber laser cutting machine mainly includes gas source, filter device and pipeline. Among them, there are two kinds of air sources: bottled air and compressed air.

    F. Machine frame
    The bed, beam, worktable, and Z-axis system of the fiber laser cutting machine are collectively referred to as the host.

    G. Control System
    It is mainly to control the machine tool, realize the movement of X, Y, Z axis, and also control the output power of the laser.
    We use Cypcut advanced version cutting software that work language English/SPANISH/RUSSIA etc

    H. Stabillizers (for your option)
    To maintain the voltage and current stable

    I. UPS (for your option)
    Supppy battery power to this machine when voltage levels drop


    Detail technicial specifications of LASER METAL cutting machine RF-1325-1500

    No.

    Item

    Brand

    Country of origin

    1

    Fiber laser generator 1500W

    JPT

    SHENZHEN,China

    2

    Lubrication system

    Automatic

    China

    3

    Laser head with auto focus

    Ray Tools BM109

    China(famous in laser cutting head)

    4

    Machine voltage

    380v 50/60hz or 220v 50/60hz



    5

    Water chiller

    CPWL-010ADR

    Shanghai,China

    6

    Mechanical driving system

    High accurate bevel rack YYC brand,PMI square rail

    TAIWAN

    7

    Control system

    BOCHU

    Shanghai,China

    8

    PC system

    Industrial computer

    TAIWAN

    9

    X axis servo unit

    Yaskawa 850w

    Japan

    10

    Y axis servo unit

    Yaskawa 850w

    Japan

    11

    Z axis servo unit

    Yaskawa 400w

    Japan

    12

    Reducer motor

    Shimpo

    Japan

    13

    Cutting software

    Cypcut 1000C

    Shanghai,China

    14

    I/O card

    Cypcut

    Shanghai,China

    15

    Working table

    Knife table with strictly hardening,tempering and annealing treatment,frame thickness 10mm

    Jinan,China

    16

    Button module

    Schneider

    China

    17

    AC Contactor

    Schneider

    China

    18

    Automatic height controller

    Ray Tools

    China

    19

    Machine net weight

    3000kg



    20

    Machine working size

    1300mmx2500mm



    21

    Production time

    12-20 working days




    Working industry:
    Widely used in decoration
    advertising sign production
    sheet metal processing
    high and low voltage electrical cabinet production
    textile machinery parts, aviation, aerospace, electronics
    kitchenware, automobiles, machinery, elevators, electrical parts, springs, subway parts, precision parts, ships
    Metallurgical equipment
    craft gifts
    tool processing
    metal external processing and other manufacturing and processing industries

    Fiber Laser cutting machine detail parts:
     Raytool BM109 model quality fiber laser head with auto focus

    TAIWAN PMI25 square rail and YYC helical rack

    Raycus 1000w fiber laser source

    Japan Yaskawa servo motor drivers 850w

    High qualityy cables with strong cable chain

    Remote handle

     SMC proportional valve

    High precison heavy duty machine structure
